  • Thermocouple, Bare Tails, ANSI, T,
  • XF-1169-FAR is an ANSI PFA insulated exposed junction thermocouple with bare tails.

    *Fast response, welded exposed junction
    *PTFE PFA insulated twin-twisted lead cable
    *Temperature range from -75°C to +250°C
    *Meets ANSI MC96.1 standard
    *1/0.3mm cable size
    *10m (32.8ft) length
  • Thermocouple, Bare Tails, BS, K,
  • XF-1199-FAR is a BS glass fibre exposed welded tip thermocouple.

    *Good temperature resistance (not suitable in fluids)
    *Exposed junction sensor type
    *2m cable length, glass fibre cable type
    *1/0.3mm core/strands
    *Bare tails termination type
    *Temperature range from -60°C to +350°C (short periods up to 400°C)
    *Colour coded to former British standard – BS1843-1952
  • Thermocouple, Durable PFA,K
  • The Z2-K-1.0-1/0.2-MP-ANSI is a Durable PFA Exposed Welded Tip Thermocouple. Fast response, welded exposed junction. PTFE PFA insulated twin-twisted lead. Miniature plug termination. Ideal for test and development application.

    K-type Thermocouple
    -75 to 250°C Operating temperature
  • Thermocouple, Miniature Plug, ANSI, K,
  • XF-1165-FAR is an ANSI PFA insulated exposed junction thermocouple.

    *K type thermocouple
    *Twin twisted cable style
    *1/0.2mm cable size
    *5m cable length
    *Miniature plug termination
    *Max temperature of +250°C
  • Thermocouple, PFA Exposed Junction, IEC, J,
  • XF-1557-FAR is an IEC PFA insulated twin twisted exposed junction thermocouple.

    *J type thermocouple
    *1/0.3mm cable size
    *5m cable length
    *Miniature plug termination
    *Temperature range from -75°C to +250°C
    *PTFE® PFA insulated twin-twisted lead cable type
